IDPC-65-700
LED DRVR CC AC/DC 69-93V 700MAManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. IDPC-65-700 is a 65W constant current LED driver with a 700mA output. This AC/DC converter topology features a single output with a voltage range of 69V to 93V. The driver offers analog and PWM dimming capabilities and achieves an efficiency of 89%. It is equipped with short-circuit protection (SCP). The IDPC-65 series operates within an input voltage range of 180VAC to 295VAC, with an isolation voltage of 3.75 kV. Its dimensions are 130.0mm x 67.5mm x 20.5mm, with terminal block termination. This component is suitable for applications in lighting and general industrial control systems, carrying approvals from CB, CE, CCC, cURus, and ENEC.
Additional Information
Series: IDPC-65 (65W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | SCP |
| Packaging | Box |
| Size / Dimension | 5.12"" L x 2.66"" W x 0.81"" H (130.0mm x 67.5mm x 20.5mm) |
| Voltage - Output | 69 ~ 93V |
| Type | Constant Current |
| Operating Temperature | -20°C ~ 40°C |
| Termination Style | Terminal Block |
| Voltage - Input (Max) | 295VAC |
| Approval Agency | CB, CE, CCC, cURus, ENEC |
| Ratings | - |
| Efficiency | 89% |
| Topology | AC DC Converter |
| Current - Output (Max) | 700mA |
| Dimming | Analog, PWM |
| Voltage - Input (Min) | 180VAC |
| Power (Watts) | 65 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
