GSC40E-500
LED DRVR CC AC/DC 40-80V 500MAManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. GSC40E-500 is a 40W Constant Current LED Driver from the GSC40E series. This AC/DC converter features a 500mA output current and a 40-80V output voltage range. Designed for efficiency, it achieves 89.5% typical efficiency and offers Short Circuit Protection (SCP). The single output driver operates within an input voltage range of 90-277VAC. It boasts 3.75 kV isolation voltage and an IP40 rating, suitable for applications in lighting and industrial automation. The unit measures 79.0mm x 54.0mm x 33.0mm and utilizes a barrel plug termination style (2.1mm I.D. x 5.5mm O.D. x 11mm). Approvals include CB, CE, ENEC, and KEMA-KEUR. Operating temperature range is -30°C to 50°C.
Additional Information
Series: GSC40E (40W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | SCP |
| Packaging | Box |
| Size / Dimension | 3.11"" L x 2.13"" W x 1.30"" H (79.0mm x 54.0mm x 33.0mm) |
| Voltage - Output | 40 ~ 80V |
| Type | Constant Current |
| Operating Temperature | -30°C ~ 50°C |
| Termination Style | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11mm |
| Voltage - Input (Max) | 277VAC |
| Approval Agency | CB, CE, ENEC, KEMA-KEUR |
| Ratings | IP40 |
| Efficiency | 89.5% |
| Topology | AC DC Converter |
| Current - Output (Max) | 500mA |
| Dimming | - |
| Voltage - Input (Min) | 90VAC |
| Power (Watts) | 40 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
