GSC40B-700
LED DRVR CC AC/DC 29-58V 700MAManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. GSC40B-700 is a 40W constant current LED driver from the GSC40B series. This AC/DC converter features a 700mA output current and a selectable output voltage range of 29V to 58V, suitable for a wide array of LED arrays. With an efficiency of 88.5% and a compact form factor of 79.0mm x 54.0mm x 33.0mm, it operates effectively within an ambient temperature range of -30°C to 50°C. The driver includes short circuit protection (SCP) and boasts an isolation voltage of 3.75 kV. Its input voltage accepts a wide range, from 90VAC to 277VAC. The GSC40B-700 is ideal for applications in general lighting and architectural lighting, with a termination style featuring a 2.1mm I.D. x 5.5mm O.D. x 11mm barrel plug. It is certified by CB, CCC, CE, ENEC, and KEMA-KEUR, and carries an IP40 rating.
Additional Information
Series: GSC40B (40W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | SCP |
| Packaging | Box |
| Size / Dimension | 3.11"" L x 2.13"" W x 1.30"" H (79.0mm x 54.0mm x 33.0mm) |
| Voltage - Output | 29 ~ 58V |
| Type | Constant Current |
| Operating Temperature | -30°C ~ 50°C |
| Termination Style | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11mm |
| Voltage - Input (Max) | 277VAC |
| Approval Agency | CB, CCC, CE, ENEC, KEMA-KEUR |
| Ratings | IP40 |
| Efficiency | 88.5% |
| Topology | AC DC Converter |
| Current - Output (Max) | 700mA |
| Dimming | - |
| Voltage - Input (Min) | 90VAC |
| Power (Watts) | 40 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
