GSC18E-500
LED DRVR CC AC/DC 18-36V 500MAManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. GSC18E series constant current LED driver, part number GSC18E-500. This 18W AC/DC converter features a single output delivering 500mA with an adjustable voltage range of 18-36V. Designed with an efficiency of 88.5%, it operates across an input voltage range of 90-277VAC and includes protection for short circuits (SCP). The unit offers 3.75 kV isolation and is rated IP40, with dimensions of 79.0mm x 54.0mm x 33.0mm. Termination is via a 2.1mm I.D. x 5.5mm O.D. x 11mm barrel plug. Approvals include CB, CE, ENEC, and KEMA-KEUR. This component is suitable for applications in general lighting and architectural lighting.
Additional Information
Series: GSC18E (18W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | SCP |
| Packaging | Box |
| Size / Dimension | 3.11"" L x 2.13"" W x 1.30"" H (79.0mm x 54.0mm x 33.0mm) |
| Voltage - Output | 18 ~ 36V |
| Type | Constant Current |
| Operating Temperature | -30°C ~ 50°C |
| Termination Style | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11mm |
| Voltage - Input (Max) | 277VAC |
| Approval Agency | CB, CE, ENEC, KEMA-KEUR |
| Ratings | IP40 |
| Efficiency | 88.5% |
| Topology | AC DC Converter |
| Current - Output (Max) | 500mA |
| Dimming | - |
| Voltage - Input (Min) | 90VAC |
| Power (Watts) | 18 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
