ELG-150U-48
LED DRVR CC/CV AC/DCManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. ELG-150U-48 is a 150W LED driver featuring a Constant Current/Constant Voltage (CC/CV) output. This AC/DC converter offers a maximum output current of 3.13A and a 48V output voltage. The driver is designed for universal AC input from 100VAC to 305VAC, with an isolation voltage of 3.75 kV. Key protective features include Over Current Protection (OCP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), and Short Circuit Protection (SCP). With an efficiency of 90%, the ELG-150U-48 operates across a wide temperature range of -40°C to 85°C (with derating). Its dimensions are 195.0mm x 63.0mm x 35.5mm, and it utilizes wire leads for termination. This component is suitable for applications in the general lighting and architectural lighting industries.
Additional Information
Series: ELG-150U (150W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | OCP, OTP, OVP, SCP |
| Packaging | Bulk |
| Size / Dimension | 7.68"" L x 2.48"" W x 1.40"" H (195.0mm x 63.0mm x 35.5mm) |
| Voltage - Output | 48V |
| Type | Constant Current, Voltage |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Termination Style | Wire Leads |
| Voltage - Input (Max) | 305VAC |
| Approval Agency | - |
| Ratings | - |
| Efficiency | 90% |
| Topology | AC DC Converter |
| Current - Output (Max) | 3.13A |
| Dimming | - |
| Voltage - Input (Min) | 100VAC |
| Power (Watts) | 150 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
