CEN-75-42
LED DRVR CC AC/DC 31.5-42V 1.8AManufacturer: MEAN WELL USA Inc.
Categories: LED Drivers
Quality Control: Learn More
MEAN WELL USA Inc. CEN-75 (75W) series constant current LED driver, part number CEN-75-42. This AC/DC converter features a single output providing 1.8A at 31.5V to 42V for LED applications. With an efficiency of 90% and a maximum input voltage of 295VAC, it operates across a wide input range of 90VAC to 295VAC. Key protection features include Over Current Protection (OCP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), and Short Circuit Protection (SCP). The driver is rated IP66 for robust environmental resistance and offers 3.75 kV isolation. Its dimensions are 164.0mm x 62.5mm x 40.5mm, terminated with wire leads. Approvals include CB, CE, cURus, PSE, and TUV. This component is suitable for general lighting and industrial applications.
Additional Information
Series: CEN-75 (75W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | OCP, OTP, OVP, SCP |
| Packaging | Box |
| Size / Dimension | 6.46"" L x 2.46"" W x 1.59"" H (164.0mm x 62.5mm x 40.5mm) |
| Voltage - Output | 31.5 ~ 42V |
| Type | Constant Current |
| Operating Temperature | -30°C ~ 70°C |
| Termination Style | Wire Leads |
| Voltage - Input (Max) | 295VAC |
| Approval Agency | CB, CE, cURus, PSE, TUV |
| Ratings | IP66 |
| Efficiency | 90% |
| Topology | AC DC Converter |
| Current - Output (Max) | 1.8A |
| Dimming | - |
| Voltage - Input (Min) | 90VAC |
| Power (Watts) | 76 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 3.75 kV |
| Programmable | Not Verified |
