XR16M698IQ100-F
IC UART FIFO 32B OCTAL 100QFPManufacturer: MaxLinear, Inc.
Categories: UARTs (Universal Asynchronous Receiver Transmitter)
Quality Control: Learn More
MaxLinear, Inc. XR16M698IQ100-F is an octal UART with a 32-byte FIFO buffer per channel. This component supports eight independent communication channels, each configurable for RS485 protocol. It features an internal oscillator and timer/counter functionalities. The device operates with a supply voltage range of 1.62V to 3.63V and offers a maximum data rate of 15Mbps. The XR16M698IQ100-F includes automatic flow control, false start bit detection, IrDA encoding/decoding capabilities, and modem control signals. Its 100-QFP (14x20) package is designed for surface mounting. This UART is suitable for applications in industrial automation, networking, and communication systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Features | Internal Oscillator, Timer/Counter |
| Packaging | Tray |
| Package / Case | 100-BQFP |
| Number of Channels | 8 |
| Mounting Type | Surface Mount |
| Voltage - Supply | 1.62V ~ 3.63V |
| FIFO's | 32 Byte |
| Protocol | RS485 |
| Data Rate (Max) | 15Mbps |
| Supplier Device Package | 100-QFP (14x20) |
| With Auto Flow Control | Yes |
| With IrDA Encoder/Decoder | Yes |
| With False Start Bit Detection | Yes |
| With Modem Control | Yes |
