XR16C854IV-F
IC UART FIFO 128B QUAD 64LQFPManufacturer: MaxLinear, Inc.
Categories: UARTs (Universal Asynchronous Receiver Transmitter)
Quality Control: Learn More
The MaxLinear XR16C854IV-F is a highly integrated UART controller featuring four independent, fully programmable UART channels. Each channel supports RS232 and RS485 communication protocols, offering robust serial data transfer capabilities. The device boasts a substantial 128-byte transmit and receive FIFO buffer per channel, significantly reducing processor overhead and enhancing system performance.
Key features include an internal oscillator, timer/counter functionality, and support for auto flow control, false start bit detection, and modem control signals. The XR16C854IV-F is designed for efficient operation with a wide supply voltage range of 2.97V to 5.5V and a maximum data rate of 2Mbps. Its inclusion of an IrDA encoder/decoder further expands its application versatility. This component is commonly utilized in industrial automation, networking equipment, and embedded systems requiring reliable multi-port serial communication. The XR16C854IV-F is supplied in a 64-pin LQFP (10x10) surface-mount package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Internal Oscillator, Timer/Counter |
| Packaging | Tray |
| Package / Case | 64-LQFP |
| Number of Channels | 4, QUART |
| Mounting Type | Surface Mount |
| Voltage - Supply | 2.97V ~ 5.5V |
| FIFO's | 128 Byte |
| Protocol | RS232, RS485 |
| Data Rate (Max) | 2Mbps |
| Supplier Device Package | 64-LQFP (10x10) |
| With Auto Flow Control | Yes |
| With IrDA Encoder/Decoder | Yes |
| With False Start Bit Detection | Yes |
| With Modem Control | Yes |
