XRP7725ILBTR-F
IC REG 6OUT BUCK/LINEAR 44TQFNManufacturer: MaxLinear, Inc.
Categories: Linear + Switching
Quality Control: Learn More
The MaxLinear, Inc. XRP7725ILBTR-F is a versatile power management IC featuring six regulated outputs. This component integrates four step-down (buck) converters with adjustable switching frequencies from 105kHz to 1.23MHz, alongside two linear low-dropout (LDO) regulators. The device supports input voltages ranging from 4.75V to 25V and is housed in a 44-lead TQFN (7x7) package suitable for surface mounting. Its architecture includes a sequencer for controlled power-up and is designed for applications in industrial, automotive, and consumer electronics requiring flexible and efficient power delivery. The XRP7725ILBTR-F is supplied on tape and reel.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 44-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 4.75V ~ 25V |
| Frequency - Switching | 105kHz ~ 1.23MHz |
| Topology | Step-Down (Buck) (4), Linear (LDO) (2) |
| Supplier Device Package | 44-TQFN (7x7) |
| Voltage/Current - Output 1 | Controller |
| Voltage/Current - Output 2 | Controller |
| Voltage/Current - Output 3 | Controller |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | Yes |
| Number of Outputs | 6 |
