XR8054ATP14MTR
IC OPAMP VFB 4 CIRCUIT 14TSSOPManufacturer: MaxLinear, Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
MaxLinear, Inc. XR8054ATP14MTR is a quad voltage feedback operational amplifier. This device features rail-to-rail output and a -3dB bandwidth of 90 MHz, with a gain bandwidth product of 260 MHz. The XR8054ATP14MTR offers a high slew rate of 190 V/µs and a typical input bias current of 1.3 µA. Each channel requires a quiescent current of 2.6 mA. The operating supply voltage range is from 2.7 V to 12.6 V. This component is housed in a 14-TSSOP package and is supplied on tape and reel, suitable for surface mount applications. The XR8054ATP14MTR finds application in various instrumentation and signal processing systems operating across the -40°C to 125°C temperature range.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | Voltage Feedback |
| Operating Temperature | -40°C ~ 125°C |
| Current - Supply | 2.6mA (x4 Channels) |
| Slew Rate | 190V/µs |
| Gain Bandwidth Product | 260 MHz |
| Current - Input Bias | 1.3 µA |
| Voltage - Input Offset | 500 µV |
| Supplier Device Package | 14-TSSOP |
| Number of Circuits | 4 |
| Current - Output / Channel | 100 mA |
| -3db Bandwidth | 90 MHz |
| Voltage - Supply Span (Min) | 2.7 V |
| Voltage - Supply Span (Max) | 12.6 V |
