OK204-25-422-OB
OLED MODULE 80DIG 20 X 4Manufacturer: Matrix Orbital
Categories: LCD, OLED Character and Numeric
Quality Control: Learn More
Matrix Orbital OK204-25-422-OB is a character display module featuring a 20x4 format with blue text on a black OLED background. This component utilizes a 5 x 8 dot character format with individual dots measuring 0.54mm W x 0.55mm H, and characters at 4.75mm H x 2.90mm W. The module offers an RS-422 interface for robust communication and operates within a voltage range of 4.75V to 5.25V. It is designed for industrial applications, including automation control and instrumentation, with an operating temperature range of -20°C to 70°C. The overall dimensions are 98.00mm x 60.00mm x 23.00mm, with a viewing area of 77.00mm L x 25.20mm W. This electronic component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Display Type | OLED |
| Display Mode | - |
| Backlight | - |
| Interface | RS-422 |
| Operating Temperature | -20°C ~ 70°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Viewing Area | 77.00mm L x 25.20mm W |
| Character Size | 4.75mm H x 2.90mm W |
| Display Format | 20 x 4 |
| Character Format | 5 x 8 Dots |
| Dot Size | 0.54mm W x 0.55mm H |
| Outline L x W x H | 98.00mm x 60.00mm x 23.00mm |
| Text Color | Blue |
| Background Color | Black |
| Number of Characters | 80.0 |
