MTSM340UV-F5120S
340NM FLAT SMD UV STARBOARDManufacturer: Marktech Optoelectronics
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
Marktech Optoelectronics MTSM340UV-F5120S is a 340nm ultraviolet (UV) emitter designed for surface mount applications. This component features a flat SMD package with a 110° viewing angle and operates with a typical forward voltage of 4.3V and a maximum forward current of 500mA. The 2-SMD, No Lead package ensures efficient thermal management and simplified board assembly. The MTSM340UV-F5120S is suitable for use in applications requiring precise UV light emission, including curing systems, germicidal irradiation, and analytical instrumentation. Operating within a temperature range of -10°C to 85°C, this emitter provides reliable performance for demanding industrial and scientific applications.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 2-SMD, No Lead |
| Wavelength | 340nm |
| Mounting Type | Surface Mount |
| Type | Ultraviolet (UV) |
| Orientation | Top View |
| Operating Temperature | -10°C ~ 85°C |
| Voltage - Forward (Vf) (Typ) | 4.3V |
| Viewing Angle | 110° |
| Current - DC Forward (If) (Max) | 500mA |
| Radiant Intensity (Ie) Min @ If | - |
