MTG7-001I-XQD00-WW-BDE7
LED MOD CREE XQ-D STARBRD 3000KManufacturer: Marktech Optoelectronics
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
The Marktech Optoelectronics MTG7-001I-XQD00-WW-BDE7 is a warm white LED module from the Cree XQ-D series, featuring a 3000K correlated color temperature. This module is designed for efficient illumination with a typical forward voltage of 3.1V and a maximum forward current of 700mA, tested at 350mA. The LED is mounted on a Starboard configuration for optimal thermal management and ease of integration. Its compact dimensions of 19.90mm x 19.90mm, combined with a 145° viewing angle and flat lens, make it suitable for a wide range of lighting applications. This component finds use in general lighting, architectural lighting, and display backlighting systems.
Additional Information
Series: Cree XQ-DRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: -Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | - |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 19.90mm L x 19.90mm W |
| Type | LED Module |
| Configuration | Starboard |
| Voltage - Forward (Vf) (Typ) | 3.1V |
| Height | - |
| Current - Test | 350mA |
| Viewing Angle | 145° |
| Lens Type | Flat |
| Current - Max | 700mA |
| Lumens/Watt @ Current - Test | - |
| CCT (K) | 3000K |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | - |
| Temperature - Test | - |
| Luminous Flux @ Current/Temperature | - |
