PT-1240PQ
BUZZER PIEZO 5V 13.8MM THManufacturer: Mallory Sonalert Products Inc.
Categories: Alarms, Buzzers, and Sirens
Quality Control: Learn More
Buzzers Transducer, Externally Driven Piezo 5 V 2mA 4.1kHz 80dB @ 5V, 10cm Through Hole PC Pins
Additional Information
Series: PTRoHS Status: ROHS3 CompliantManufacturer Lead Time: 25 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Size / Dimension | 0.543"" Dia (13.80mm) |
| Mounting Type | Through Hole |
| Frequency | 4.1kHz |
| Operating Temperature | -20°C ~ 70°C |
| Sound Pressure Level (SPL) | 80dB @ 5V, 10cm |
| Duration | - |
| Current - Supply | 2mA |
| Input Type | Peak-Peak Signal |
| Operating Mode | Single Tone |
| Voltage Range | 1 ~ 20V |
| Technology | Piezo |
| Termination | PC Pins |
| Approval Agency | - |
| Ratings | - |
| Port Location | Top |
| Driver Circuitry | Transducer, Externally Driven |
| Height - Seated (Max) | 0.335"" (8.50mm) |
| Voltage - Rated | 5 V |
