MX25U6432FZCI02
IC FLASH 64MBIT SPI/QUAD 8XSONManufacturer: Macronix
Categories: Memory
Quality Control: Learn More
The Macronix MX25U6432FZCI02 is a 64Mbit NOR Flash memory component from the MXSMIO™ series. This non-volatile memory features a Quad SPI/QPI interface, enabling high-speed data transfer at up to 133 MHz with an access time of 6 ns. The memory organization options include 16M x 4, 32M x 2, and 64M x 1. Packaged in an 8-XSON (4x4) surface-mount configuration, this component operates within a voltage range of 1.65V to 2V and an ambient temperature range of -40°C to 85°C. Typical applications include consumer electronics, industrial control, and automotive systems.
Additional Information
Series: MXSMIO™RoHS Status: unknownManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-XDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Memory Size | 64Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 1.65V ~ 2V |
| Technology | FLASH - NOR (SLC) |
| Clock Frequency | 133 MHz |
| Memory Format | FLASH |
| Supplier Device Package | 8-XSON (4x4) |
| Write Cycle Time - Word, Page | 40µs, 3ms |
| Memory Interface | SPI - Quad I/O, QPI |
| Access Time | 6 ns |
| Memory Organization | 16M x 4, 32M x 2, 64M x 1 |
