MX25L12845GZNI-10G
IC FLASH 128MBIT SPI 8WSONManufacturer: Macronix
Categories: Memory
Quality Control: Learn More
Macronix MX25L12845GZNI-10G is a 128Mbit NOR Flash memory device utilizing the Serial Peripheral Interface (SPI). This component, part of the MX25xxx45 - MXSMIO™ series, operates at a clock frequency of up to 120 MHz and features a memory organization of 16M x 8. It is supplied in an 8-WSON (8x6) package with surface mount capability. The device supports a supply voltage range of 2.7V to 3.6V and operates within an ambient temperature range of -40°C to 85°C. Write cycle times for word and page operations are specified at 30µs and 750µs, respectively. This non-volatile memory is suitable for applications in the automotive, industrial, and consumer electronics sectors.
Additional Information
Series: MX25xxx45 - MXSMIO™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 8-WDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Memory Size | 128Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.7V ~ 3.6V |
| Technology | FLASH - NOR |
| Clock Frequency | 120 MHz |
| Memory Format | FLASH |
| Supplier Device Package | 8-WSON (8x6) |
| Write Cycle Time - Word, Page | 30µs, 750µs |
| Memory Interface | SPI |
| Memory Organization | 16M x 8 |
| Programmable | Not Verified |
