JANTX1N969BUR-1
DIODE ZENER 22V 500MW DO213AAManufacturer: MACOM Technology Solutions
Categories: Single Zener Diodes
Quality Control: Learn More
Zener Diode 22 V 500 mW ±5% Surface Mount DO-213AA
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BulkDownload Free CAD Model:
Technical Details:
| Tolerance | ±5% |
| Packaging | Bulk |
| Package / Case | DO-213AA (Glass) |
| Mounting Type | Surface Mount |
| Operating Temperature | -65°C ~ 175°C |
| Voltage - Zener (Nom) (Vz) | 22 V |
| Impedance (Max) (Zzt) | 29 Ohms |
| Supplier Device Package | DO-213AA |
| Grade | Military |
| Power - Max | 500 mW |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 200 mA |
| Current - Reverse Leakage @ Vr | 5 µA @ 16.7 V |
| Qualification | MIL-PRF-19500/117 |
