WS1A3640-V1-R3K
RF MOSFET GAN 48V 20LGAManufacturer: MACOM Technology Solutions
Categories: RF FETs, MOSFETs
Quality Control: Learn More
MACOM Technology Solutions WS1A3640-V1-R3K is a Gallium Nitride (GaN) RF MOSFET designed for high-performance applications. This component operates with a 48V test voltage and delivers 10W of output power across a frequency range of 3.3GHz to 3.8GHz. It features a 12.5dB gain and a test current rating of 70mA. The device is housed in a 20-LGA (6x6) package with an exposed pad, facilitating efficient thermal management. Its robust GaN technology makes it suitable for demanding applications in sectors such as radar, defense, and wireless communications. The WS1A3640-V1-R3K is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 28 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-TFLGA Exposed Pad |
| Current Rating (Amps) | - |
| Mounting Type | Surface Mount |
| Frequency | 3.3GHz ~ 3.8GHz |
| Configuration | - |
| Power - Output | 10W |
| Gain | 12.5dB |
| Technology | GaN |
| Noise Figure | - |
| Supplier Device Package | 20-LGA (6x6) |
| Voltage - Rated | 125 V |
| Voltage - Test | 48 V |
| Current - Test | 70 mA |
