PTFC270051M-V2-R0
RF MOSFET LDMOS 28V 10SONManufacturer: MACOM Technology Solutions
Categories: RF FETs, MOSFETs
Quality Control: Learn More
MACOM Technology Solutions PTFC270051M-V2-R0 is a high-performance RF LDMOS power transistor designed for demanding applications. Operating across a frequency range of 900MHz to 2.7GHz, this component delivers a typical gain of 19.5dB and a power output of 5W. It features a 28V test voltage and a 65V rated voltage, with a continuous drain current of 65mA at the test condition. The PTFC270051M-V2-R0 is housed in a 10-LDFN exposed pad package (PG-SON-10) suitable for surface mounting and supplied in tape and reel packaging. This device is commonly utilized in base station infrastructure and industrial heating applications.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-LDFN Exposed Pad |
| Current Rating (Amps) | 1µA |
| Mounting Type | Surface Mount |
| Frequency | 900MHz ~ 2.7GHz |
| Power - Output | 5W |
| Gain | 19.5dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | PG-SON-10 |
| Voltage - Rated | 65 V |
| Voltage - Test | 28 V |
| Current - Test | 65 mA |
Request a Quote
