SDS120J002C3-ISATH
DIODE 1200V-2A TO220-2LManufacturer: Luminus Devices Inc.
Categories: Single Diodes
Quality Control: Learn More
Diode 1200 V 11A Through Hole TO-220-2L
Additional Information
Series: Sanan TO220RoHS Status: ROHS3 CompliantManufacturer Lead Time: 7 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 |
| Mounting Type | Through Hole |
| Speed | No Recovery Time > 500mA (Io) |
| Reverse Recovery Time (trr) | 0 ns |
| Technology | SiC (Silicon Carbide) Schottky |
| Capacitance @ Vr, F | 165pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 11A |
| Supplier Device Package | TO-220-2L |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 2 A |
| Current - Reverse Leakage @ Vr | 8 µA @ 1200 V |
