PT-120-R-C11-MPD
LED MOD PT-120 RED RECTManufacturer: Luminus Devices Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
The Luminus Devices Inc. PT-120 series LED Module, part number PT-120-R-C11-MPD, is a red, rectangular LED module designed for high-density illumination applications. This module features a typical forward voltage of 2.3V and a maximum current rating of 36A, with a test current of 18A yielding 24 lm/W. It provides a luminous flux of 1010lm (Typ) at 624nm wavelength. The Light Emitting Surface (LES) measures 2.60mm L x 4.63mm W within a 28.00mm L x 42.00mm W footprint, standing 5.61mm high. This component is suitable for use in demanding lighting solutions and is supplied in trays.
Additional Information
Series: PT-120RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | Red |
| Wavelength | 624nm |
| Size / Dimension | 28.00mm L x 42.00mm W |
| Type | LED Module |
| Configuration | Rectangle |
| Voltage - Forward (Vf) (Typ) | 2.3V |
| Height | 5.61mm |
| Current - Test | 18A |
| Viewing Angle | - |
| Lens Type | Flat |
| Current - Max | 36A |
| Lumens/Watt @ Current - Test | 24 lm/W |
| CCT (K) | - |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | 2.60mm L x 4.63mm W |
| Temperature - Test | 40°C |
| Luminous Flux @ Current/Temperature | 1010lm (Typ) |
