L1V2-40700000CABL0
LED LUXEON NEUT WHT 4000K 3535Manufacturer: Lumileds
Categories: LED White Lighting
Quality Control: Learn More
Lumileds LUXEON V2 L1V2-40700000CABL0 is a neutral white LED designed for high-performance lighting applications. This component features a Color Temperature of 4000K with a typical Color Rendering Index (CRI) of 70. It operates with a forward voltage of 2.83V (typ.) and a test current of 700mA, achieving a typical luminous flux of 315 lumens at 85°C. The efficacy at this test current is 159 lm/W. The LED is housed in a 1414 (3535 Metric) surface-mount package with dimensions of 3.45mm x 3.45mm and a seated height of 2.39mm. It offers a wide 120° viewing angle. Maximum current capability is 1.2A. This component is commonly utilized in automotive lighting, general illumination, and architectural lighting sectors. It is supplied on tape and reel.
Additional Information
Series: LUXEON V2RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1414 (3535 Metric) |
| Color | White, Neutral |
| Size / Dimension | 0.136"" L x 0.136"" W (3.45mm x 3.45mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.83V |
| Current - Test | 700mA |
| Viewing Angle | 120° |
| Current - Max | 1.2A |
| Supplier Device Package | 3535 |
| Lumens/Watt @ Current - Test | 159 lm/W |
| Height - Seated (Max) | 0.094"" (2.39mm) |
| CCT (K) | 4000K |
| CRI (Color Rendering Index) | 70 |
| Flux @ 25°C, Current - Test | - |
| Flux @ 85°C, Current - Test | 315lm (Typ) |
