L135-27800BHV00001
LED LUXEON WARM WHITE 2700K 2SMDManufacturer: Lumileds
Categories: LED White Lighting
Quality Control: Learn More
Lumileds LUXEON 3535 HV series LED, part number L135-27800BHV00001, offers a warm white 2700K color temperature with a typical CRI of 80. This surface-mount component, packaged in a 3535 metric (1414) footprint, operates at a nominal forward voltage of 24V. At a test current of 15mA, it provides a typical luminous flux of 41 lumens with a luminous efficacy of 114 lm/W. The maximum continuous forward current is rated at 30mA. This LED is supplied on tape and reel for automated assembly and is suitable for general illumination and architectural lighting applications. Its compact dimensions are 0.138 inches in length by 0.134 inches in width, with a maximum seated height of 0.035 inches.
Additional Information
Series: LUXEON 3535 HVRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1414 (3535 Metric) |
| Color | White, Warm |
| Size / Dimension | 0.138"" L x 0.134"" W (3.50mm x 3.40mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 24V |
| Current - Test | 15mA |
| Viewing Angle | - |
| Current - Max | 30mA |
| Supplier Device Package | 3535 |
| Lumens/Watt @ Current - Test | 114 lm/W |
| Height - Seated (Max) | 0.035"" (0.90mm) |
| CCT (K) | 2700K |
| CRI (Color Rendering Index) | 80 |
| Flux @ 25°C, Current - Test | 41lm (Typ) |
| Flux @ 85°C, Current - Test | - |
