LXML-PB02
LED LUXEON REBEL BLUE 470NM SMDManufacturer: Lumileds
Categories: LED Color Lighting
Quality Control: Learn More
Lumileds LUXEON Rebel Color ES LXML-PB02 is a high-flux, blue surface-mount LED designed for demanding lighting applications. This component features a typical forward voltage of 2.95V and a peak wavelength of 470nm. Optimized for efficiency, it achieves 32 lm/W at a test current of 700mA, delivering 67 lumens at 25°C. The LXML-PB02 supports a maximum continuous drive current of 1A. Housed in an 1812 (4532 Metric) footprint, its dimensions are 0.177" L x 0.120" W (4.49mm x 3.05mm) with a maximum seated height of 0.083" (2.10mm). The viewing angle is 125°. This LED is supplied on tape and reel, suitable for automated assembly in industries such as architectural lighting, automotive, and general illumination.
Additional Information
Series: LUXEON Rebel Color ESRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1812 (4532 Metric) |
| Color | Blue |
| Wavelength | 470nm (Typ) |
| Size / Dimension | 0.177"" L x 0.120"" W (4.49mm x 3.05mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.95V |
| Current - Test | 700mA |
| Viewing Angle | 125° |
| Current - Max | 1A |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 32 lm/W |
| Height - Seated (Max) | 0.083"" (2.10mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 67lm (50lm ~ 83lm) |
Request a Quote
Clients Also Buy
LXML-PR02-A900
LED LUXEON REBEL BLUE 448NM SMD
LXML-PX02-0000
