L1RX-RED1000000000
LED LUXEON RUBIX RED 625NM 1414Manufacturer: Lumileds
Categories: LED Color Lighting
Quality Control: Learn More
LED Lighting Color LUXEON Rubix Color Red 625nm 0505 (1313 Metric)
Additional Information
Series: LUXEON Rubix ColorRoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 0505 (1313 Metric) |
| Color | Red |
| Wavelength | 625nm |
| Size / Dimension | 0.055"" L x 0.055"" W (1.40mm x 1.40mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.3V |
| Current - Test | 1.5A |
| Viewing Angle | 125° |
| Current - Max | 2.2A |
| Supplier Device Package | 1414 |
| Lumens/Watt @ Current - Test | 23 lm/W |
| Height - Seated (Max) | 0.037"" (0.93mm) |
| Temperature - Test | 85°C |
| Luminous Flux @ Current/Temperature | 80lm (75lm ~ 85lm) |
