L2C1-2780120206A00
LED COB LUXEON WM WHT RECT 2700KManufacturer: Lumileds
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Lumileds LUXEON CoB L2C1-2780120206A00 is a warm white LED Chip On Board (COB) module. This component features a 2700K color temperature with a 3-Step MacAdam ellipse for tight color uniformity, and a CRI of 80. The rectangular light-emitting surface (LES) is 6.50mm in diameter, and the module itself measures 12.00mm L x 15.00mm W with a low profile of 1.50mm height. Operating at a test current of 200mA and a maximum current of 400mA, it achieves 102 lm/W and a typical luminous flux of 725lm at 85°C. The forward voltage is typically 35.5V. This COB is commonly utilized in general lighting, downlighting, and spotlight applications where high efficacy and excellent optical control are critical. The viewing angle is 115°, and it is supplied in tubes.
Additional Information
Series: LUXEON CoBRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 12.00mm L x 15.00mm W |
| Type | Chip On Board (COB) |
| Configuration | Rectangle |
| Voltage - Forward (Vf) (Typ) | 35.5V |
| Height | 1.50mm |
| Current - Test | 200mA |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 400mA |
| Lumens/Watt @ Current - Test | 102 lm/W |
| CCT (K) | 2700K 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | 6.50mm Dia |
| Temperature - Test | 85°C |
| Luminous Flux @ Current/Temperature | 725lm (Typ) |
