SSL-LX100133XGC
LED GREEN CLEAR T-10MM T/HManufacturer: Lumex Opto/Components Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Lumex Opto/Components Inc. SSL-LX100133XGC is a through-hole mounted green LED designed for discrete indication applications. This T-10mm radial component features a clear, colorless lens with a domed top, measuring 10mm in diameter. It operates with a typical forward voltage of 2.1V and a test current of 20mA, achieving a luminous intensity of 1600 millicandelas at its peak wavelength of 570nm. The narrow viewing angle of 8° makes it suitable for applications requiring precise light directionality. This component is commonly utilized in industrial automation, medical instrumentation, and consumer electronics for status indication. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Green |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 1600mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 8° |
| Height (Max) | 13.50mm |
| Wavelength - Peak | 570nm |
| Wavelength - Dominant | - |
| Supplier Device Package | T-10mm |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 10.00mm Dia |
