SML-LXL1209SIC-TR
LED RED CLEAR 1209 SMDManufacturer: Lumex Opto/Components Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Red LED Indication - Discrete 2V 1209 (3224 Metric)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 1209 (3224 Metric) |
| Color | Red |
| Size / Dimension | 3.20mm L x 2.40mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 600mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 30° |
| Height (Max) | 2.70mm |
| Wavelength - Peak | 636nm |
| Wavelength - Dominant | - |
| Supplier Device Package | 1209 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 1.80mm Dia |
Request a Quote
