SSF-LXH101GD-01
LED CBI 5MM GRN RA PC MNTManufacturer: Lumex Opto/Components Inc.
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
Lumex Opto/Components Inc. SSF-LXH101GD-01 is a Green LED Circuit Board Indicator. This single, diffused, and tinted LED features a round, domed top lens measuring 5mm (T-1 3/4). It operates at a forward voltage of 2.2V and a current of 20mA, with a typical millicandela rating of 30mcd and a peak wavelength of 565nm. The mounting style is through-hole with a right-angle orientation, suitable for PC board assembly. The viewing angle is 60°. This component finds application in industrial control systems, telecommunications equipment, and consumer electronics where status indication is critical. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Current | 20mA |
| Color | Green |
| Voltage Rating | 2.2V |
| Mounting Type | Through Hole, Right Angle |
| Millicandela Rating | 30mcd |
| Configuration | Single |
| Viewing Angle | 60° |
| Lens Type | Diffused, Tinted |
| Wavelength - Peak | 565nm |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
