1.5KE30A
TVS DIODE 25.6VWM 41.4VC DO201Manufacturer: Littelfuse Inc.
Categories: TVS Diodes
Quality Control: Learn More
41.4V Clamp 36.7A Ipp Tvs Diode Through Hole DO-201
Additional Information
Series: 1.5KERoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-201AA, DO-27, Axial |
| Mounting Type | Through Hole |
| Type | Zener |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 36.7A |
| Voltage - Reverse Standoff (Typ) | 25.6V |
| Supplier Device Package | DO-201 |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 28.5V |
| Voltage - Clamping (Max) @ Ipp | 41.4V |
| Power - Peak Pulse | 1500W (1.5kW) |
| Power Line Protection | No |
