QJ8030LH4TP
TRIAC ALTERNSTR 800V 30A TO220ABManufacturer: Littelfuse Inc.
Categories: TRIACs
Quality Control: Learn More
TRIAC Alternistor - Snubberless 800 V 30 A Through Hole TO-220AB-L
Additional Information
Series: QJxx30LH4RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 Isolated Tab |
| Mounting Type | Through Hole |
| Triac Type | Alternistor - Snubberless |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Hold (Ih) (Max) | 60 mA |
| Current - Gate Trigger (Igt) (Max) | 35 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 290A, 350A |
| Voltage - Gate Trigger (Vgt) (Max) | 1 V |
| Supplier Device Package | TO-220AB-L |
| Current - On State (It (RMS)) (Max) | 30 A |
| Voltage - Off State | 800 V |
