L4006L8
TRIAC SENS GATE 400V 6A TO220Manufacturer: Littelfuse Inc.
Categories: TRIACs
Quality Control: Learn More
Littelfuse Inc. L4006L8 is a single TRIAC designed for high-reliability switching applications. This component features a sensitive gate, requiring a maximum gate trigger voltage of 1.3 V and a maximum gate trigger current of 10 mA for activation. It offers an on-state current rating of 6 A (RMS) and a non-repetitive surge current capability of 50 A / 60 A at 50 Hz / 60 Hz. The L4006L8 boasts a 400 V off-state voltage and a hold current of 20 mA (max). Its TO-220 isolated tab package facilitates through-hole mounting and operation within an ambient temperature range of -40°C to 110°C. This TRIAC is commonly utilized in industrial automation, motor control, and lighting control systems where precise and reliable AC power switching is paramount.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-3 Isolated Tab |
| Mounting Type | Through Hole |
| Triac Type | Logic - Sensitive Gate |
| Configuration | Single |
| Operating Temperature | -40°C ~ 110°C (TJ) |
| Current - Hold (Ih) (Max) | 20 mA |
| Current - Gate Trigger (Igt) (Max) | 10 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 50A, 60A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V |
| Supplier Device Package | TO-220 Isolated Tab |
| Current - On State (It (RMS)) (Max) | 6 A |
| Voltage - Off State | 400 V |
