LBA710
SSR RELAY SPST-NO/NC 1A 0-60VManufacturer: Littelfuse Inc.
Categories: Solid State Relays (SSR)
Quality Control: Learn More
Littelfuse Inc. LBA710 is a Solid State Relay from the OptoMOS® LBA series. This component offers a dual pole configuration, providing both a normally open (SPST-NO, 1 Form A) and a normally closed (SPST-NC, 1 Form B) circuit within a single 8-DIP (0.300" / 7.62mm) package. It supports AC and DC output types with a load voltage range of 0V to 60V and a maximum load current of 1A. The input voltage requirement is 1.2VDC. Featuring a through-hole mounting type, the LBA710 exhibits a maximum on-state resistance of 600 mOhms. Approved by CSA, TUV, and UL, this relay is suitable for applications across industrial automation, telecommunications, and medical equipment sectors. The operating temperature range is -40°C to 85°C.
Additional Information
Series: LBA, OptoMOS®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Output Type | AC, DC |
| Mounting Type | Through Hole |
| Voltage - Input | 1.2VDC |
| Circuit | SPST-NO + SPST-NC (1 Form A and B) |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Load Current | 1 A |
| Approval Agency | CSA, TUV, UL |
| Supplier Device Package | 8-DIP |
| Grade | - |
| Voltage - Load | 0 V ~ 60 V |
| On-State Resistance (Max) | 600 mOhms |
| Qualification | - |
