CPC1510GSTR
SSR RELAY SPST-NO 200MA 0-250VManufacturer: Littelfuse Inc.
Categories: Solid State Relays (SSR)
Quality Control: Learn More
Littelfuse Inc. CPC, OptoMOS® CPC1510GSTR is a Solid State Relay featuring a Single Pole Single Throw Normally Open (SPST-NO) configuration. This surface-mount device, housed in a 6-SMD (0.300", 7.62mm) package with gull wing termination, offers a load current capability of 200 mA and a load voltage range of 0 V to 250 V (AC/DC). The on-state resistance is a maximum of 15 Ohms, with a typical input voltage requirement of 1.37 VDC. Approved by CSA, TUV, and UL, this component operates within an ambient temperature range of -40°C to 85°C. It finds application in various industries including industrial automation and test and measurement equipment. The component is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: CPC, OptoMOS®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 34 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-SMD (0.300"", 7.62mm) |
| Output Type | AC, DC |
| Mounting Type | Surface Mount |
| Voltage - Input | 1.37VDC |
| Circuit | SPST-NO (1 Form A) |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | Gull Wing |
| Load Current | 200 mA |
| Approval Agency | CSA, TUV, UL |
| Supplier Device Package | 6-SMD |
| Grade | - |
| Voltage - Load | 0 V ~ 250 V |
| On-State Resistance (Max) | 15 Ohms |
| Qualification | - |
