IXFP34N65X3
MOSFET 34A 650V X3 TO220Manufacturer: Littelfuse Inc.
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 650 V 34A (Tc) 446W (Tc) Through Hole TO-220-3 (IXFP)
Additional Information
Series: HiPerFET™, Ultra X3RoHS Status: ROHS3 CompliantManufacturer Lead Time: 32 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 34A (Tc) |
| Rds On (Max) @ Id, Vgs | 100mOhm @ 17A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 446W (Tc) |
| Vgs(th) (Max) @ Id | 5.2V @ 2.5mA |
| Supplier Device Package | TO-220-3 (IXFP) |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 650 V |
| Gate Charge (Qg) (Max) @ Vgs | 29 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2025 pF @ 25 V |
