IXFH56N30X3
MOSFET N-CH 300V 56A TO247Manufacturer: Littelfuse Inc.
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 300 V 56A (Tc) 320W (Tc) Through Hole TO-247 (IXTH)
Additional Information
Series: HiPerFET™, Ultra X3RoHS Status: ROHS3 CompliantManufacturer Lead Time: 32 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 56A (Tc) |
| Rds On (Max) @ Id, Vgs | 27mOhm @ 28A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 320W (Tc) |
| Vgs(th) (Max) @ Id | 4.5V @ 1.5mA |
| Supplier Device Package | TO-247 (IXTH) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 300 V |
| Gate Charge (Qg) (Max) @ Vgs | 56 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 3750 pF @ 25 V |
