BD540-30
PTC RESET FUSE 16V 21A RADIALManufacturer: Littelfuse Inc.
Categories: PTC Resettable Fuses
Quality Control: Learn More
Polymeric PTC Resettable Fuse 16V 21 A Ih Through Hole Radial, Disc
Additional Information
Series: PolySwitch®, BD540RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Radial, Disc |
| Size / Dimension | 0.987"" L x 0.384"" W (25.08mm x 9.75mm) |
| Mounting Type | Through Hole |
| Type | Polymeric |
| Operating Temperature | - |
| Lead Spacing | 0.392"" (9.95mm) |
| Current - Hold (Ih) (Max) | 21 A |
| Current - Trip (It) | 40 A |
| Voltage - Max | 16V |
| Ratings | - |
| Height - Seated (Max) | 0.880"" (22.36mm) |
| Thickness (Max) | - |
| Current - Max | 100 A |
| Time to Trip | 13 s |
| Resistance - Initial (Ri) (Min) | 1.6 mOhms |
| Resistance - Post Trip (R1) (Max) | 4.4 mOhms |
