MG06400D-BN1MM
IGBT MODULE 600V 460A 1400W D3Manufacturer: Littelfuse Inc.
Categories: IGBT Modules
Quality Control: Learn More
Littelfuse Inc. MG06400D-BN1MM is a Half Bridge IGBT Module designed for demanding power applications. This component offers a robust 600 V collector-emitter breakdown voltage and a substantial 460 A continuous collector current, with a maximum power dissipation of 1400 W. The module features a standard input configuration and a Vce(on) of 2.45V at 15V gate-emitter voltage and 400A collector current. Input capacitance (Cies) is rated at 18 nF at 25 V. The MG06400D-BN1MM utilizes a D3 package for chassis mounting, facilitating efficient thermal management. This IGBT module is suitable for use in industrial motor drives, power supplies, and electric vehicle powertrains.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | D-3 Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Half Bridge |
| Operating Temperature | - |
| Vce(on) (Max) @ Vge, Ic | 2.45V @ 15V, 400A |
| NTC Thermistor | No |
| Supplier Device Package | D3 |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 460 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Power - Max | 1400 W |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 18 nF @ 25 V |
