0253003.M
FUSE BRD MNT 3A 125VAC/VDC AXIALManufacturer: Littelfuse Inc.
Categories: Fuses
Quality Control: Learn More
Littelfuse Inc. PICO® II 253 Series axial fuse, part number 0253003-M, offers a 3A rating with a 125VAC/VDC voltage rating. This board mount fuse features a fast-blow response time and a breaking capacity of 50A at 125VAC and 300A at 125VDC. The compact axial package measures 2.61mm x 7.11mm (0.103" Dia x 0.280" L). Operating across a wide temperature range of -55°C to 125°C, this component is suitable for applications in industrial, telecommunications, and consumer electronics sectors. The fuse meets CCC, CSA, PSE, QPL, TUV, and UR approval standards. Delivered in bulk packaging, it provides reliable overcurrent protection for demanding circuit designs.
Additional Information
Series: PICO® II 253RoHS Status: ROHS3 CompliantManufacturer Lead Time: 32 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Axial |
| Color | - |
| Size / Dimension | 0.103"" Dia x 0.280"" L (2.61mm x 7.11mm) |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C |
| Response Time | Fast Blow |
| Approval Agency | CCC, CSA, PSE, QPL, TUV, UR |
| Breaking Capacity @ Rated Voltage | 50A AC, 300A DC |
| Current Rating (Amps) | 3 A |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 125 V |
| Melting I²t | 1.19 |
