JLLN300.X
FUSE CRTRDGE 300A 300VAC/125VDCManufacturer: Littelfuse Inc.
Categories: Electrical, Specialty Fuses
Quality Control: Learn More
300A 300 VAC 125 VDC Fuse Cartridge Bolt Mount
Additional Information
Series: POWR-GARD® JLLNRoHS Status: ROHS3 CompliantManufacturer Lead Time: 11 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Box |
| Package / Case | Cylindrical, Blade Terminal (Bolt) |
| Size / Dimension | 1.311"" Dia x 0.827"" L (33.30mm x 21.00mm) |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 300A |
| Mounting Type | Bolt Mount |
| Operating Temperature | - |
| Response Time | Fast Blow |
| Applications | Electrical, Industrial |
| Approval Agency | CE, CSA, UL |
| Class | T |
| Breaking Capacity @ Rated Voltage | 200kA AC, 20kA DC |
| Voltage Rating - AC | 300 VAC |
| Voltage Rating - DC | 125 VDC |
