K2400F2
SIDAC 220-250V 1A TO202Manufacturer: Littelfuse Inc.
Categories: DIACs, SIDACs
Quality Control: Learn More
Littelfuse Inc. SIDAC K2400F2 is a robust bidirectional voltage-triggered semiconductor switch. This device, housed in a TO-202 package with a long tab, features a breakover voltage range of 220 to 250V. It is designed to handle a peak output current of 1A, with a specified breakover current of 10µA and a maximum holding current of 150mA. The K2400F2 operates reliably across an extended temperature range from -40°C to 125°C (TJ). This component finds application in surge protection, overvoltage limiting, and power control circuits within industrial automation, telecommunications, and power distribution systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-202 Long Tab |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Current - Hold (Ih) (Max) | 150 mA |
| Voltage - Breakover | 220 ~ 250V |
| Current - Breakover | 10 µA |
| Supplier Device Package | TO-202 |
| Current - Peak Output | 1 A |
