LTST-C930CKT
LED RED CLEAR CHIP SMDManufacturer: Lite-On Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Lite-On Inc. Red 638nm LED, part number LTST-C930CKT, is a discrete surface-mount component designed for indication. This 1209 (3224 Metric) package features a clear, colorless lens with a domed top, providing a 25° viewing angle. The LED operates with a typical forward voltage of 1.8V and a test current of 20mA, achieving a millicandela rating of 320mcd. Its dominant wavelength is 638nm, with a peak wavelength of 660nm. The component measures 3.20mm L x 2.40mm W x 2.40mm H (Max) and is supplied on tape and reel. This component is commonly utilized in industrial automation, consumer electronics, and medical device applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 1209 (3224 Metric) |
| Color | Red |
| Size / Dimension | 3.20mm L x 2.40mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 320mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.8V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 25° |
| Height (Max) | 2.40mm |
| Wavelength - Peak | 660nm |
| Wavelength - Dominant | 638nm |
| Supplier Device Package | Chip LED |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 1.80mm Dia |
