LTST-008RGB
LED RGB CLEAR 615NM 525NM 460NMManufacturer: Lite-On Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Lite-On Inc. LTST-008RGB is a discrete RGB LED component featuring individual wavelength outputs of 615nm (Red), 525nm (Green), and 460nm (Blue). This clear lens LED provides distinct luminous intensities of 600mcd for Red, 950mcd for Green, and 200mcd for Blue at a typical 20mA test current. Forward voltage requirements are 2.1V for Red and 3.3V for Green and Blue. The LTST-008RGB offers a wide 120° viewing angle and is supplied in Tape & Reel packaging. This component is suitable for various indication applications across industries such as consumer electronics, industrial automation, and automotive systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | - |
| Color | Red, Green, Blue (RGB) |
| Size / Dimension | - |
| Mounting Type | - |
| Millicandela Rating | 600mcd Red, 950mcd Green, 200mcd Blue |
| Configuration | - |
| Voltage - Forward (Vf) (Typ) | 2.1V Red, 3.3V Green, 3.3V Blue |
| Lens Color | Colorless |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue |
| Viewing Angle | 120° |
| Height (Max) | - |
| Wavelength - Peak | 623nm Red, 518nm Green, 455nm Blue |
| Wavelength - Dominant | 615nm Red, 525nm Green, 460nm Blue |
| Supplier Device Package | - |
| Lens Transparency | Clear |
| Lens Style | Rectangle with Flat Top |
| Lens Size | - |
