LTL42EVHJNT
LED RED DIFFUSED T-1 T/HManufacturer: Lite-On Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Lite-On Inc. LTL42EVHJNT is a red diffused T-1 through-hole LED with a dominant wavelength of 618nm and peak wavelength of 624nm. This discrete LED component features a forward voltage of 2V (typical) and a test current of 20mA, delivering 680mcd luminous intensity. The T-1 radial package has a 3mm lens with a diffused finish and a domed top, providing a 40° viewing angle. Its white lens color contributes to its diffused output. This component is commonly found in industrial automation, medical equipment, and consumer electronics for status indication.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 680mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2V |
| Lens Color | White |
| Current - Test | 20mA |
| Viewing Angle | 40° |
| Height (Max) | 6.55mm |
| Wavelength - Peak | 624nm |
| Wavelength - Dominant | 618nm |
| Supplier Device Package | T-1 |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
