LTS-4301B
DISPLAY 7SEG 0.39"" SGL BLU 10DIPManufacturer: Lite-On Inc.
Categories: LED Character and Numeric
Quality Control: Learn More
Lite-On Inc. LTS-4301B is a single-digit, 7-segment display module featuring a blue LED character height of 0.39 inches (10.00mm). This component utilizes a common cathode configuration and operates with a typical forward voltage of 3.8V and a test current of 20mA. The display offers a peak wavelength of 428nm and a luminous intensity of 3.6mcd. Its compact dimensions are 0.508" H x 0.382" W x 0.276" D (12.90mm x 9.70mm x 7.00mm). The LTS-4301B is packaged in a 10-DIP (0.300", 7.62mm) format, suitable for through-hole mounting. Applications for this display module can be found in industrial control panels, test and measurement equipment, and various embedded systems requiring clear numerical indication.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 10-DIP (0.300"", 7.62mm) |
| Color | Blue |
| Display Type | 7-Segment |
| Size / Dimension | 0.508"" H x 0.382"" W x 0.276"" D (12.90mm x 9.70mm x 7.00mm) |
| Number of Characters | 1 |
| Millicandela Rating | 3.6mcd |
| Common Pin | Common Cathode |
| Digit/Alpha Size | 0.39"" (10.00mm) |
| Voltage - Forward (Vf) (Typ) | 3.8V |
| Current - Test | 20mA |
| Wavelength - Peak | 428nm |
| Power Dissipation (Max) | 65mW |
