LTL-42M6NMHKP
LED CBI 3MM 3X1 GREEN/REDManufacturer: Lite-On Inc.
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
Lite-On Inc. LTL-42M6NMHKP is a 3mm, T-1 LED Circuit Board Indicator. This component features a 3-high configuration with two green LEDs and one red LED. Each LED is diffused and tinted with a round, domed top lens style, providing a 60° viewing angle. The forward voltage ratings are 2.1V for green and 2V for red, with an operating current of 90mA for both colors. The peak wavelengths are 565nm for green and 635nm for red, with typical millicandela ratings of 12.6mcd for green and 8.7mcd for red. This indicator is supplied in tray packaging and is commonly utilized in industrial control systems, test and measurement equipment, and consumer electronics for status indication.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Current | 90mA Green, 90mA Red |
| Color | Green (x 2), Red (x 1) |
| Voltage Rating | 2.1V Green, 2V Red |
| Millicandela Rating | 12.6mcd Green, 8.7mcd Red |
| Configuration | 3 High |
| Viewing Angle | 60° |
| Lens Type | Diffused, Tinted |
| Wavelength - Peak | 565nm, 635nm |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
