LI-IMX490-GW5400-GMSL2-065H
SONY DIAGONAL 10.36 MM (TYPE 1/1Manufacturer: Leopard Imaging Inc.
Categories: Camera Modules
Quality Control: Learn More
Leopard Imaging Inc. offers the LI-IMX490-GW5400-GMSL2-065H, a high-performance camera module featuring the SONY IMX490 sensor. This module delivers a resolution of 2880 x 1860 pixels with a 3µm x 3µm pixel size, capturing detailed RGB imagery. Designed for demanding applications, it supports a frame rate of 25.0 fps. The component utilizes a GMSL2 interface for high-bandwidth data transfer and is housed in a compact 1.181" x 1.181" (30.00mm x 30.00mm) chassis mount module with an M12 lens mount. Its robust construction includes a maximum height of 2.568" (65.22mm). This camera module is suitable for use in automotive, industrial automation, and advanced imaging systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Color | RGB |
| Size / Dimension | 1.181"" L x 1.181"" W (30.00mm x 30.00mm) |
| Mounting Type | Chassis Mount |
| Interface | USB 3.0 |
| Type | CMOS |
| Pixel Size | 3µm x 3µm |
| Resolution | 2880 x 1860 |
| Height (Max) | 2.568"" (65.22mm) |
| Supplier Device Package | - |
| Frames per Second | 25.0 |
| Shutter | - |
| Sensor | IMX490 |
| Lens Mount | M12 |
