LT 1005-T/SP4
TRANSDUCERManufacturer: LEM USA Inc.
Categories: Current Sensors
Quality Control: Learn More
LEM USA Inc. presents the LT-1005-T-SP4, a closed-loop Hall effect current transducer designed for high-precision measurement applications. This module offers a 1000A sensing capability with bidirectional, single-pass-through current measurement. Engineered for accuracy, it boasts ±0.4% typical accuracy and ±0.1% linearity. The LT-1005-T-SP4 operates across a wide frequency range from DC up to 150kHz, supporting both AC and DC current measurements. It requires a supply voltage between 15V and 24V, with a maximum supply current of 30mA. The module features a fast 1µs response time and is designed for robust performance within an operating temperature range of -40°C to 85°C. Mounting is facilitated via a chassis mount configuration. This component is suitable for demanding applications in industries such as industrial automation, power conversion, and renewable energy systems.
Additional Information
Series: LTRoHS Status: RoHS CompliantManufacturer Lead Time: 14 week(s)Product Status: Not For New DesignsPackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module, Single Pass Through |
| Polarization | Bidirectional |
| Sensitivity | - |
| Mounting Type | Chassis Mount |
| Output | - |
| Frequency | DC ~ 150kHz |
| Accuracy | ±0.4% |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 15V ~ 24V |
| Response Time | 1µs |
| Sensor Type | Hall Effect, Closed Loop |
| Linearity | ±0.1% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 30mA |
| Current - Sensing | 1000A |
| Supplier Device Package | - |
| Grade | - |
| Number of Channels | 1 |
| Qualification | - |
