HO 200-S-0107
SENSOR CURRENT HALL AC/DCManufacturer: LEM USA Inc.
Categories: Current Sensors
Quality Control: Learn More
LEM USA Inc. HO-S Series HO-200-S-0107 is an open-loop Hall effect current sensor module designed for AC/DC measurements up to 200A. This single-pass-through module offers a ratiometric voltage output with a sensitivity of 4mV/A and linearity of ±0.5%. It operates with a supply voltage of 4.5V to 5.5V and has a maximum supply current of 25mA. The component features a frequency response up to 100kHz and is suitable for chassis mounting. Operating within a temperature range of -40°C to 105°C, the HO-200-S-0107 is utilized in various industrial automation, power supply, and motor control applications.
Additional Information
Series: HO-SRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module, Single Pass Through |
| Polarization | - |
| Sensitivity | 4mV/A |
| Mounting Type | Chassis Mount |
| Output | Ratiometric, Voltage |
| Frequency | 100kHz |
| Accuracy | - |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Response Time | - |
| Sensor Type | Open Loop |
| Linearity | ±0.5% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 25mA |
| Current - Sensing | 200A |
| Number of Channels | 1 |
