HAW 03-P
SENSOR CURRENT HALL 3A AC/DCManufacturer: LEM USA Inc.
Categories: Current Sensors
Quality Control: Learn More
LEM USA Inc. HAW series HAW-03-P Hall Effect current sensor. This open-loop, single-channel sensor is designed for bidirectional AC/DC current measurement up to 3A. Featuring a ratiometric voltage output, it offers ±1% accuracy and linearity across a frequency range from DC to 50kHz. The HAW-03-P is housed in an 8-DIP module with through-hole mounting. It operates with a supply voltage of ±15V and a maximum supply current of 18mA, with a typical response time of 3µs. This component is widely utilized in industrial automation, power supplies, and motor control applications.
Additional Information
Series: HAWRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-DIP Module |
| Polarization | Bidirectional |
| Sensitivity | - |
| Mounting Type | Through Hole |
| Output | Ratiometric, Voltage |
| Frequency | DC ~ 50kHz |
| Accuracy | ±1% |
| Operating Temperature | -10°C ~ 75°C |
| Voltage - Supply | ±15V |
| Response Time | 3µs |
| Sensor Type | Hall Effect, Open Loop |
| Linearity | ±1% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 18mA |
| Current - Sensing | 3A |
| Supplier Device Package | - |
| Number of Channels | 1 |
